BUBBLE FOG MACHINE

WP-2 bubble fog machine is the first bubble blaster from DJPOWER. It comes with patented Jet-design which makes lot of vivid bubbles filled with fog with less fog outside. The excess bubble fluid will flow to waste storage bin instead of dropping on the ground. To protect bubble fluid from getting bad and ensure high quality bubbles, bubble fluid is well stored in the tank. With this feature, the unit can also be mounted high in the truss, launching bubbles all over the sky. No matter for shows, concerts, parties and events, this unit will be pretty good choice.

WP-2 USER MANUAL INQUIRE NOW
WP-2



Features

Jet design, produce lots of bubbles filled with fog.

Well-designed heating system releases the fog evenly and purely, no fluid dropping off.

Two fans make the fog bubble fly higher, further.

Bubble and fog fluid storage in separately.

The excess bubble fluid will flow back to waste fluid tank.

Combining with Led light.

Built-in LCD control, wireless remote control and 3-pin and 5-pin DMX control.




Specifications
AC POWER

Input Voltage & Rate: 220-240 V, 50/60 Hz

Current Limiter Type: Breaker

Current Limiter Specifications: 5 A, 250 V

Total Power Consumption: 650 W

Power Input Connector: Lockable PowerCon

Power Output Connector (Daisy Chained): Lockable PowerCon

HEATING

Heat Up Time: Appr. 3 min

Heater Type: Aluminum Heater Block

LIGHT SOURCE

LED Color: RGBY

LED Type: Quad-Color

Power per LED: 8 W

Quantity of LED: 6 pcs

Total Power of LED: 48 W

CAPACITY

Haze Fluid Tank Capacity: 1.3 L

Bubble Fluid Tank Capacity: 1.3 L

OUTPUT

Adjustable Volume: √

Max Output Volume: Appr. 4,500 cuft/min

Max Output Height: Appr. 4 m

Max Output Distance: Appr. 3.5 m

Haze Fluid Consumption Rate: Appr. 60 min/L

Bubble Fluid Consumption Rate: Appr. 40 min/L

FEATURES

Physical Thermostat: ×

Electronic Thermo-Control: √

Adjustable Output : √

Adjustable Fan Speed: √

No-Fluid Protection: ×

On-device Manual Control : LCD control board

Wireless Control: W-2

Wired Control: ×

Control Protocol: DMX-512

DMX Channel Range: 12

Data Connectors: 3- and 5-pin XLR

ACCESSORY

Power Cord: √

Omega Bracket: √

Wireless Controller Model: W-2

CONSUMABLE

Consumable: PRO-PW and PRO-C or PRO-J

WEIGHT&DIMENSIONS

Net Weight: 13.7kg

Gross Weight: 16.3 kg

Machine Dimensions: 422 × 317 × 422.4 mm

Packing Dimensions:  535 × 435 × 500 mm
