HF-90S is DJPOWER's newly upgraded vertical flame machine, and flame effect reaches up to 8-10 m. It is equipped with dual ignition, rainproof structure design, built-in fuel tank and pumping system which makes it easy to operate and powerful. It is suitable for all kinds of shows to create excellent atmosphere.
Dual ignition ensures successful ignition；
Fast and precise flame burst;
Rainproof structure design, IPX3 waterproof grade;
Intelligent electronic control system (Pressure & no-fluid monitoring; Safety & Failure warning) ;
Built-in LCD control, 3-pin and 5-pin DMX control;
Full set of SEETRONIC rainproof power connectors;
With battery interface, support external 12V battery supply.
Note: The actual effect may be affected by the use environment.
In order to protect the oil pump and pipeline, 10-20ML castor oil must be added to every 10L of fuel, otherwise the oil pump and components will be damaged)
Input Voltage & Rate: 220-240 V, 50/60 Hz
Current Limiter Type: Breaker
Current Limiter Specifications: 5 A, 250 V
Total Power Consumption: 450 W
Power Input Connector: Lockable PowerCon
Fluid Tank Capacity: 5 L
Adjustable Output Angle: ×
Max Output Height: Appr. 8 m (no wind)
Fluid Consumption Rate: Appr. 0.4 min/L
Consumable: Isopropyl alcohol, Bio-Ethanol, Isopar-G
Physical Thermostat: ×
Electronic Thermo-Control: ×
Adjustable Output : ×
No-fluid Monitoring: √
Safety Warning: √
Failure Warning: √
On-device Manual Control : LCD control board
Wireless Control: ×
Wired Control: √
Control Protocol: DMX-512
DMX Channel Range: 2 or 6
Data Connectors: 3- and 5-pin XLR
Power Cord: √
Wireless Controller Model: ×
Consumables: Isopar-G (or isopropyl alcohol, bio-ethanol, please consult a sales representative for this type of consumables)
Net Weight: 17.5 kg
Gross Weight: 20.8 kg
Machine Dimensions: 335 × 297.3 × 383.4 mm
Packing Dimensions: 490 × 440 × 505 mm
