HF-P10

TCFLAMER

TCFlamer HF-P10 is a tube flame machine launched by DJPOWER that uses liquid fuel as fuel. It is specially designed for outdoor use. The waterproof level reaches IP67. With DJPOWER' s fuel feeder TCPumper DH-2.4, it can realize remote fuel supply. Through DMX control and infrared remote control, remote non-contact settings can be realized, and the safety performance is higher. The flame erupted up to about 10 meters, and the explosive force was full. Suitable for major outdoor activities that need to create a fiery atmosphere.

HF-P10 USER MANUAL

INQUIRE NOW NEXT PRODUCT

Features

Aluminum alloy housing, imported fuel nozzles, IP67 waterproof rating;

Double igniter, fast injection, safe and reliable;

Adjustable height unto 10 meters(no wind), more explosive;

Controlled by DMX;

Through infrared remote control, remote non-contact settings can be realized;

Built-in Accumulator;

Customized voltage 220V, 110V and so on.

Specifications

AC POWER

Input Voltage & Rate: 220-240 V, 50/60 Hz ( Customizable )

Total Power Consumption: 120 W

Power Input Connector: Lockable PowerCon

OUTPUT

Max Output Height: Appr. 10 m (no wind)

Fluid Consumption Rate: Appr. 0.4 min/L

Max Continuous Duration@full volume: Appr. 8 s

CONTROL

Work Pressure : 8-10 bar

Body Control: Digital display

Control Protocol: Infrared remote control

Control Protocol: DMX-512

DMX Channel Range: 2 or 6

IP RATE

IP Rate: IP 67

CONSUMABLE

Consumables: Isopar-G (or isopropyl alcohol, bio-ethanol, please consult a sales representative for this type of consumables)

WEIGHT & DIMENSIONS

Net Weight: 17.5 kg

Gross Weight: 21.6 kg

Machine Dimensions: 256 × 200 × 428 mm

Packing Dimensions: 560 × 330 × 375 mm
