H-20V

TOPCO2JET

H-20V is a new dual-nozzle super jet fog machine launched by DJPOWER. It can achieve rapid air column effects without the need of CO2 cylinders. High-speed airflow assist technology enhances fog spray speed. The dual-nozzle design can spray up to 15-meter high air column with majestic effects! It has 37pcs of 8W LEDs, producing strong and colorful air columns. The special effects fog machine has independent R&D high-speed airflow assist patent (No: ZL202023001465.9), Super-jet patent (No: ZL201520934500.2), Immediate-stop patent (No: ZL201320700998.7). It's suitable for large-scale performances, bars, cultural tourism projects etc.


H-20V



Features

High-speed airflow assiatance technology, rapid eruptions and quick dissipation;

Dual ouput creats huge fog column up to 15 meters;

 super-jet and lmmediate-stop functions make the fog react very quickly;

 With 37pcs 8W RGB/Amber LEDs, produce colorful fog column;

Supports side-way, upside down installation and multi-angle spraying;


Please use DJPOWER professional High Density Nano Fog Fluid PRO-20V. It has high density which produces pure, white and dense fog.

The nano fog particles can dissipate faster. The effect is more outstanding when used with H-20V.

Note: The actual effect may be affected by the actual environment.


DMX fog machine applications

Concerts & Nightclubs: Create immersive atmospheres with dense fog and colorful effects that enhance lighting and engage audiences.

Theaters & Stage Productions: Simulate realistic environmental conditions for plays, musicals, and other performances.

Outdoor Events & Festivals: The robust design makes it ideal for use in parks, gardens, and other open spaces.

Themed Parties: Add a magical touch to events with customizable fog and lighting effects.


Company Services

Expert Technical Support: Our team is available to assist with setup, troubleshooting, and maintenance.

Quality Assurance: Every DMX fog machine undergoes rigorous testing to ensure reliability and performance.

Comprehensive After-Sales Service: We offer extended warranties, financing options, and ongoing customer support.

Specialized Fluid Solutions: Keep your super jet fog machine running with high-quality fog fluid (PRO-20V) for optimal performance.




Specifications
AC POWER

Input Voltage & Rate:AC 220-240 V, 50/60 Hz

Total Power Consumption:3,100 W

HEATING

Heat-up time:Appr. 6 min

LIGHT SOURCE

37pcs x 8W RGB/Amber

OUTPUT

Max Output Volume: Appr. 117,000 cuft/min

Max Output Height: Appr. 15 m

Fluid Consumption @ full volume : Appr. 1.8 min/L

Maximum Continuous Duration @ full volume: Appr.10 s

Fully-loaded Cumulative Output Duration @ full volume: Appr. 9 min

CAPACITY

Fluid Tank Capacity: 5 L

CONSUMABLE

Consumable: PRO-20V

CONTROL

On-device Manual Control : LCD Control Board

Control Protocol: DMX512

DMX Channel Range: 15 or 16

WEIGHT & DIMENSIONS

Net Weight: 33 kg

Gross Weight: 37 kg

Machine Dimensions: 594 × 304 × 439 mm

Packing Dimensions: 710 × 445 × 500 mm
